Product Features

l  Supports 9.95Gb/s to 11.3Gb/s bit rates

l  DWDM EML transmitter and APD receiver

l  100 GHz ITU channel spacing with integrated wavelength locker

l  Up to 80km on 9/125µm SMF

l  Hot-pluggable XFP footprint

l  Supports Lineside and XFI loopback

l  Built-in digital diagnostic functions

l  Full Duplex LC connector

l  RoHS compliant and lead-free

l  Single +3.3V power supply

l  No Reference Clock required

l  Power dissipation <1.5W

l  Metal enclosure, for lower EMI

l  Meet ESD requirements, resist 8KV direct contact voltage

l  Case operating temperature : 0°C to +70°C/ -40°C to +85°C


分享+
订购信息
产品型号传输速率
(Gb/s)
波长
(nm)
距离
(Km)
激光器发射光功率
(dBm)
接收器接收灵敏度
(dBm)
温度
(℃)
规格书
BIDI LX1.25 1310/1490 10 FP -9.0~-3.0 PIN < -20 -40~85
BIDI EX1.25 1310/1550 40 DFB -5~0 PIN <-24 -40~85
BIDI ZX1.25 1490/1550 80 DFB 0~5 PIN <-26 -40~85
BIDI ZX+1.25 1490/1550 120 DFB 0~5 APD < -31 -40~85
BIDI ZX++1.25 1490/1550 160 DFB 1~6 APD < -33 -40~85
