Product Features

l  Supports 9.95Gb/s to 11.3Gb/s bit rates

l  1490nm EML laser and APD receiver

l  Up to 80km on 9/125µm SMF

l  Hot-pluggable XFP footprint

l  Duplex LC/UPC type pluggable optical interface

l  RoHS compliant and lead-free

l  Support Digital Diagnostic Monitoring interface

l  Single +3.3V power supply

l  Maximum power consumption 2.0W

l  No Reference Clock required

l  Metal enclosure, for lower EMI

l  Meet ESD requirements, resist 8KV direct contact voltage

l  Case operating temperature : 0°C to +70°C/ -40°C to +85°C


分享+
订购信息
产品型号传输速率
(Gb/s)
波长
(nm)
距离
(Km)
激光器发射光功率
(dBm)
接收器接收灵敏度
(dBm)
温度
(℃)
规格书
SFP LX BIDI1.25 1310/1490 10 FP -9.0~-3.0 PIN < -20 0~70/-40~85
SFP EX BIDI1.25 1310/1550 40 DFB -5~0 PIN <-24 0~70/-40~85
SFP ZX BIDI1.25 1490/1550 80 DFB 0~5 PIN <-26 0~70/-40~85
SFP ZX+ BIDI1.25 1490/1550 120 DFB 0~5 APD < -31 0~70/-40~85
SFP ZX++ BIDI1.25 1490/1550 160 DFB 1~6 APD < -33 0~70/-40~85
