Product Features

l  Supports 9.95Gb/s to 11.3Gb/s bit rates

l  DWDM EML transmitter and PIN receiver

l  100 GHz ITU channel spacing with integrated wavelength locker

l  Up to 40km on 9/125µm SMF

l  Hot-pluggable XFP footprint

l  Supports Lineside and XFI loopback

l  Built-in digital diagnostic functions

l  Full Duplex LC connector

l  RoHS compliant and lead-free

l  Single +3.3V power supply

l  No Reference Clock required

l  Power dissipation <1.5W

l  Metal enclosure, for lower EMI

l  Meet ESD requirements, resist 8KV direct contact voltage

l  Case operating temperature : 0°C to +70°C/ -40°C to +85°C


分享+
订购信息
产品型号传输速率
(Gb/s)
波长
(nm)
距离
(Km)
激光器发射光功率
(dBm)
接收器接收灵敏度
(dBm)
温度
(℃)
规格书
CWDM LX1.25 1270-1610 20 DFB -9~-3 PIN <-20 -40~85
CWDM EX1.25 1270-1610 40 DFB -5~0 PIN <-24 -40~85
CWDM ZX1.25 1270-1610 80 DFB 0~5 PIN <-26 -40~85
CWDM ZX+1.25 1470-1610 100 DFB 0~5 APD <-30 -40~85
CWDM ZX++1.25 1470-1610 120 DFB 0~5 APD <-30 -40~85
CWDM ZX++++1.25 1470-1610 160 DFB 1~6 APD <-33 -40~85
